Forklift Carriage - There are 4 sizings of hook type fork carriages rated by the tine carriage lifting capacity. Hook type tine carriages have been consistent.
Class I carriages are rated for loads up to 2000 lbs. The carriage bar spacing for Class I is 13 inches. Class II carriages are rated for cargo as much as 5,550 lbs. Their carriage bar spacing is 16 inches. Class III carriages are rated for loads up to 10,000 lbs. The carriage bar spacing for this class is twenty inches. Class IV carriages are rated for cargo as much as 15,500 lbs. The carriage bar spacing for this capacity is twenty five inches.
Pin mounted blades vary by the amount of offset between the tine and the tine eye. Some manufacturers will differ the carriages for pin type blades. Carriage capacity will be determined by the carriage pin size and by the tine size.
